| Picture | Model | DN(mm) | Rated Flow(m³/h) | Rated Head(m) | Max. Head(m) | Voltage(V) | Frequency(Hz) | Power(W) | Port-to-port length(mm) | Pipe connection/Flange |
|---|---|---|---|---|---|---|---|---|---|---|
 |
Basic 25-20SZ | 25 | 9 | 14 | 20 | 230/380 | 50 | 1000/770/670 | 268 | G1 1/2 |
 |
Basic 25-16SZ | 25 | 7 | 12.5 | 16 | 230/380 | 50 | 700/550/410 | 222 | G1 1/2 |
 |
Basic 25-12SZXL | 25 | 5 | 8.5 | 12 | 230 | 50 | 500/460/440 | 229 | G1 1/2 |
 |
Basic 25-9SZXL | 25 | 5 | 5 | 9 | 230 | 50 | 300/280/260 | 209 | G1 1/2 |
 |
Mega 25-8 | 20 | 26 | 110/230 | 60 | 130 | 6 1/2 | Threaded | ||
 |
Mega 25-10 | 20 | 32 | 110/230 | 60 | 185 | 6 1/2 | Threaded | ||
 |
LPA 25-8 | 25 | 2.5 | 4.5 | 8 | 230 | 50/60 | 70 | 130/150/180 | G1 1/2 |
 |
LPA 25-6 | 25 | 2 | 3 | 6 | 230 | 50/60 | 45 | 130/150/180 | G1 1/2 |
 |
LPA 25-5 | 25 | 2 | 2.4 | 5 | 230 | 50/60 | 32 | 130/150/180 | G1 1/2 |
 |
LPA 25-4 | 25 | 1.7 | 2 | 4 | 230 | 50/60 | 22 | 130/150/180 | G1 1/2 |
 |
Master SD 25-4 | 25 | 1.8 | 2 | 4 | 220~240 | 50/60 | 25 | 130/180 | G1 1/2 |
 |
Master SD 25-5 | 20 | 2 | 2.7 | 5 | 220~240 | 50/60 | 33 | 130/180 | G1 1/2 |
 |
Master SD 25-6 | 25 | 2 | 3.5 | 6 | 220~240 | 50/60 | 39 | 130/180 | G1 1/2 |
 |
Master SD 25-7 | 25 | 2.2 | 4 | 6 | 220~240 | 50/60 | 52 | 130/180 | G1 1/2 |
 |
Master SD 25-7.5 | 25 | 2.2 | 4.7 | 7.5 | 220~240 | 50/60 | 60 | 130/180 | G1 1/2 |
 |
Master SD 25-8 | 25 | 2.5 | 6.5 | 8 | 220~240 | 50/60 | 70 | 130/180 | G1 1/2 |
 |
Master D 25-4 | 25 | 1.8 | 2 | 4 | 220~240 | 50/60 | 25 | 130/180 | G1 1/2 |
 |
Master D 25-5 | 25 | 2.2 | 4.7 | 7.5 | 220~240 | 50/60 | 33 | 130/180 | G1 1/2 |
 |
Master D 25-6 | 25 | 2 | 3.5 | 6 | 220~240 | 50/60 | 39 | 130/180 | G1 1/2 |
 |
Master D 25-7 | 25 | 2.2 | 4 | 7 | 220~240 | 50/60 | 52 | 130/180 | G1 1/2 |
|
Master D 25-7.5 | 25 | 2.2 | 4.7 | 7.5 | 220~240 | 50/60 | 60 | 130/180 | G1 1/2 |
 |
Master D 25-8 | 25 | 2.2 | 5.5 | 8 | 220~240 | 50/60 | 70 | 130/180 | G1 1/2 |
 |
Classic 25-4 | 25 | 1.7 | 2 | 4 | 230 | 50/60 | 22 | 130/180 | G1 1/2 |
 |
Classic S 25-5 | 25 | 2 | 2.4 | 5 | 230 | 50/60 | 32 | 130/180 | G1 1/2 |
 |
Classic S 25-6 | 25 | 2 | 3 | 6 | 230 | 50/60 | 45 | 130/180 | G1 1/2 |
 |
Classic 25-5 | 25 | 2 | 2.4 | 5 | 230 | 50/60 | 32 | 130/180 | G1 1/2 |
 |
Classic 25-7.5 | 25 | 2.5 | 4.5 | 7.5 | 230 | 50/60 | 70 | 130/180 | G1 1/2 |
 |
Classic 25-6 | 25 | 2 | 3 | 6 | 230 | 50/60 | 45 | 130/180 | G1 1/2 |
 |
Classic E 25-5 | 25 | 2 | 2.4 | 5 | 230 | 50/60 | 32 | 130/180 | G1 1/2 |
 |
Classic S 25-7.5 | 25 | 2.5 | 4.5 | 7.5 | 230 | 50/60 | 70 | 130/180 | G1 1/2 |
