| Picture | Model | DN(mm) | Rated Flow(m³/h) | Rated Head(m) | Max. Head(m) | Voltage(V) | Frequency(Hz) | Power(W) | Port-to-port length(mm) | Pipe connection/Flange |
|---|---|---|---|---|---|---|---|---|---|---|
 |
Grand 32-17 Pro | 32 | 5 | 12 | 17 | 220~240 | 50/60 | 350 | 180 | G 1 1/2 |
|
Grand 25-17 Pro | 25 | 5 | 12 | 17 | 220~240 | 50/60 | 350 | 180 | G 1 1/2 |
|
Grand 32-15 Pro | 32 | 5.5 | 11 | 15 | 220~240 | 50/60 | 300 | 180 | G 1 1/2 |
|
Grand 25-15 Pro | 25 | 5.5 | 11 | 15 | 220~240 | 50/60 | 300 | 180 | G 1 1/2 |
|
Grand 32-13 Pro | 32 | 4 | 8 | 13 | 220~240 | 50/60 | 195 | 180 | G 1 1/2 |
|
Grand 25-13 Pro | 25 | 4 | 8 | 13 | 220~240 | 50/60 | 195 | 130/180 | G 1 1/2 |
|
Grand 32-11 Pro | 32 | 3.5 | 8 | 11 | 220~240 | 50/60 | 160 | 180 | G 1 1/2 |
 |
Master H 20-9 Pro | 20 | 2.5 | 6.5 | 9 | 220~240 | 50/60 | 95 | 130 | G 1 |
 |
Master H 25-7.5 Pro | 25 | 2.2 | 4.7 | 7.5 | 220~240 | 50/60 | 60 | 130/180 | G 1 1/2 |
 |
Master H 20-7.5 Pro | 20 | 2.2 | 4.7 | 7.5 | 220~240 | 50/60 | 60 | 130 | G 1 |
 |
Master H 25-6 Pro | 25 | 2 | 3.2 | 6 | 220~240 | 50/60 | 39 | 130/180 | G 1 1/2 |
 |
Master H 20-6 Pro | 20 | 2 | 3.3 | 6 | 220~240 | 50/60 | 39 | 130 | G 1 |
 |
Master H 25-9 Pro | 25 | 4.5 | 6.5 | 9 | 220~240 | 50/60 | 95 | 130/180 | G 1 1/2 |
|
Grand 25-11 Pro | 25 | 3.5 | 7.5 | 11 | 220~240 | 50/60 | 140 | 130/180 | G 1 1/2 |
