| Imagen | Modelo | DN(mm) | Rated Flow(m³/h) | Rated Head(m) | Max. Head(m) | Voltage(V) | Frequency(Hz) | Power(W) | Port-to-port length(mm) | Pipe connection/Flange |
|---|---|---|---|---|---|---|---|---|---|---|
 |
Basic 25-16 | 25 | 7 | 12.5 | 16 | 230 | 50/60 | 700 | 230 | G1 1/2 |
 |
Basic 32-16S | 32 | 7 | 12.5 | 16 | 380 | 50 | 700 | 230 | G2 |
 |
Basic 40-12SF | 40 | 8 | 10 | 12 | 380 | 50 | 700 | 250 | DN40 |
 |
Basic 65-8SF Pro | 65 | 20 | 4.2 | 8.4 | 380 | 50 | 700 | 340 | DN65 |
 |
Basic 32-20S | 32 | 9 | 14 | 20 | 380 | 50 | 1000 | 230 | G2 |
 |
Basic 80-12SF Pro | 80 | 25 | 10 | 12 | 380 | 50 | 1500 | 360 | DN80 |
 |
Basic 65-18SF | 65 | 37 | 24 | 17.5 | 380 | 50 | 1800 | 340 | Flange |
 |
Basic 80-12SF | 80 | 28 | 7.5 | 12 | 380 | 50 | 1300 | 360 | DN80 |
